Mackie ProFX6v3 6-Channel Sound Reinforcement Mixer with Built-In FX
SKU code: 48749
- 2 x Mic/Line Inputs
- 2 x Mono/Stereo Line Inputs
- 2-In / 4-Out USB (24-Bit, 192 kHz)
- Gig FX Effects Engine (24 FX Presets)
- Main XLR & 1/4" Outputs + Headphone Out
- 2 x Onyx Mic Preamps with 48V Phantom
- 2-Band EQ on Channels 1-2
- Monitor & FX Sends, Stereo & FX Returns
- Includes Power Supply
You May Also Like
The Essentials:
Action Mounts:
Bags, Cases & Straps:
Tripods & Monopods:
Flashes & Lighting:
Cleaning & Maintenance:
Protection & Waterproof:
Viewfinder & LCD:
Audio Equipment:
Studio Lighting:
Cables & Connectivity:
Storage:
Other:
Powerful Mixing Console
The Mackie ProFX6v3 is a 6-channel mixing console that packs a punch. It features two Onyx microphone preamps with 60 dB of headroom, plus a built-in effects engine with 24 built-in FX. This makes it perfect for live sound, home recording and content creators. Plus, the integrated 2x4 USB audio interface offers high-quality 24-bit / 192 kHz recording and playback with zero-latency monitoring.
Channels 1-2 offer combo XLR-1/4" mic/line connections and feature Hi-Z (for guitar and bass), low-cut filters (100 Hz), gain controls, 2-band EQ, stereo linking, level faders, and FX send. Channels 3-4 offer two 1/4" inputs and feature a level control, while channels 5-6 use a 3.5mm stereo input with level fader. Engaging channel 5-6's USB3-4 switch will override the 3.5" input and enables the USB return from a computer. The master output is controlled with a dedicated level knob and features XLR and 1/4" connectors, while the dedicated 1/4" TRS headphone output includes an independent level control. Other features include Input-USB 1-2 blend control, FX mute, and FX to main.
Professional Sound Quality
Equipped with 2 Onyx Mic Pres offering up to 60 dB of gain and ultralow noise performance.
All-new GigFX Effects Engine with 24 different FX options, from reverbs to delays and more.
Essential Mixing Tools
2-band EQ (80 Hz and 12 kHz) on channels 1/2.
Hi-Z switches allows direct connection of guitars, basses, and other instruments.
100 Hz low-cut filter and 48V phantom power on all mic channels.
Line inputs on channel 3/4.
Stereo 1/8" input on channel 5/6.
Headphone output with separate level and blend control.
24-Bit / 192 kHz 2x4 USB Recording Interface
2x4 USB I/O allows you to create two custom mixes on your computer to send back in to the mixer.
Perfect for live performance recording, music playback, live streaming, and more.
Latency-Free Monitoring
Easily blend between monitoring your computers output and a direct feed from the mixer.
Professional Production Content
Pro Tools | First and Waveform OEM professional software and plugin packages included.
The Musician Collection for ProTools | First includes 23 plugins including 304 EQ, 304C Compressor, BBD Delay, Black Op Distortion, Black Shiny Wah, Black Spring Reverb, C1 Chorus, DC Distortion, Eleven Lite, Flanger, Graphic EQ, Gray Compressor, Green JRC Overdrive, In-Tune, Orange Phaser, Roto Speaker, Sci-Fi, Studio Reverb, Tape Echo, Tri Knob Fuzz, Vari-Fi, Vibe, Phaser, and White Boost.
The DAW Essentials Bundle for Waveform OEM includes 16 powerful plugins like Equalizer, Compressor, Reverber8, and Limiter.
Signature Rugged Design
Mackie built-like-a-tank design.
Solid steel chassis protects your investment.
Tough ABS side protection.
| MIXER | |
| Number of Analog Input Channels | 6 |
| Number of Mic Preamps | 2 |
| Analog Output Channels | 2 x Stereo Master Output |
| 1 x Stereo Headphone Output | |
| Meters | Main Meter: |
| 2 x 8-Segment LED | |
| Meter Range | Main Meter: |
| -24 dB to +14 dB Plus Peak/Clip | |
| SIGNAL PROCESSING | |
| EQ Parameters | Low: ±15 dB at 80 Hz |
| High: ±15 dB at 12 kHz | |
| Filters | High-Pass: 100 Hz, 18 dB/Octave |
| Built-In Effects | 24 x Preset (Factory) |
| DIGITAL AUDIO | |
| Bit Depth | 24-Bit |
| PERFORMANCE | |
| Frequency Response | Mic Input to Output: |
| 20 Hz to 30 kHz +0/-1 dB (Unity Gain) | |
| Max Input Level | +22 dB |
| Output Level | Main Output: |
| +28 dBu at Max Gain | |
| All Other Output: | |
| +22 dBu at Max Gain | |
| I/O Impedance | Mic Input: |
| 3.8 Kilohms | |
| Insert Return: | |
| 10 Kilohms | |
| Line Input: | |
| ≥ 20 Kilohms | |
| Headphone Output: | |
| 25 Ohms | |
| Main Output: | |
| 120 Ohms (Unbalanced) | |
| 240 Ohms (Balanced) | |
| Crosstalk | Adjacent Inputs: |
| -90 dB at 1 kHz | |
| Input to Output: | |
| -80 dB at 1 kHz | |
| Fader Off: | |
| -75 dB at 1 kHz | |
| Muted: | |
| -90 dB at 1 kHz | |
| CMRR | 70 dB at Max Gain (1 kHz, Mic In to Main Out) |
| EIN | -126 dBu at Max Gain (150-Ohm Input) |
| Noise Floor | All Outputs: |
| -95 dBu (Master Level at -∞, Channel Levels at -∞) | |
| -80 dBu (Master Level at Unity, One Channel Level at Unity) | |
| THD+N | Mic Input to Main Output: |
| < 0.03% (+4 dBu) | |
| CONNECTIVITY | |
| Phantom Power | +48 V, Selectable On/Off (Applied to All Inputs) |
| USB | 1 x USB-B 2.0() |
| USB I/O Capacity | 2 x Input / 4 x Output |
| POWER | |
| AC Input Power | Universal: |
| 100 to 240 VAC, 50 / 60 Hz | |
| Power Supply Output | 12 VDC at 2 A |
| PHYSICAL | |
| Dimensions | 7.1 x 19 x 21.3 cm |
| Weight | 1.2 kg |
* Specifications subject to change by the manufacturer without notice
- Mackie ProFX6v3 6-Channel Sound Reinforcement Mixer with Built-In FX
- USB Cable
- Power Supply
- Serial Number for Download of Pro Tools | First, Waveform OEM, and The Musician Collection
Manufacturer Warranty
This product comes with a
12 month Australian warranty
from Mackie Australia
